Thông Số Kỹ Thuật
| AC A (RMS) |
|
|---|---|
| Range | 4.000/40.00/400.0A |
| Accuracy | ±3%rdg±5dgt[45-500Hz]
(At the center of the circle formed by the flexible sensor) |
| Crest factor
(CF) |
Full scale CF<1.6, half scale<3.2
Effective input crest values are √2 times of the max values of each range. |
| Conductor size | Ø70mm max. |
| Influence of
Conductor position |
Additional ±2% (max.) depending on the distance from the center position |
| Overload protection | 500A AC for 10 seconds |
| Applicable standards | IEC 61010-1, IEC 61010-2-032
CAT Ⅳ 600V / CAT Ⅲ 1000V Pollution degree 2 IEC 61326-1(EMC) , IEC 60529 IP40 , EN50581(RoHS) |
| Operating temperature
& humidity |
0 – +50℃,less than 80% RH (without condensation) |
| Storage temperature
& humidity |
-10 – +60℃,less than 70% RH (without condensation) |
| Power source | R03 / LR03(AAA)(1.5V)×2 ※Continuous measuring time：approx.120hours (Auto power off：approx.15 minutes) |
| Dimensions | 120(L)×70(W)×26(D)：Display unit
φ5.5mm approx.：Cable diameter 1.8m approx.：Cable length |
| Weight | 200g approx. (including batteries) |
| Included Accessories | 9174 (Carrying case)
LR03(AAA)×2, Insruction manual |
