Máy hiện sóng lưu trữ kỹ thuật số dòng GDS-2000E

Tính năng, đặc điểm

• 200/100/70MHz Bandwidth Selection; 2 or 4 Channels
• 1GSa/s Real-Time Sampling Rate for Each Channel (2ch model) ; 1GSa/s Maximum Real-Time Sampling Rate (4ch model)
• Per Channel 10M Memory depth and VPO Waveform Display Technology
• Waveform Update Rate of 120,000 wfm/s
• 8 ” WVGA TFT LCD Display
• FFT with Maximum 1M points to Provide Higher Frequency Domain Resolution Measurement
• High and Low Pass Digital Filter Functions
• 29,000 Sections of Segmented Memory and Waveform Search Functions
• I2C/SPI/UART/CAN/LIN Serial Bus Trigger and Decoding Function
• Data Log Function Tracks Signal Changes Up To 100 hours
• Provide Remote Internet Storage Function

Tải file Thông số kỹ thuật: GDS-2000E (English Version)
