Thông Số Kỹ Thuật
| AC A | 40/300A ±1%rdg±4dgt [50/60Hz] (0 – 40A)
±2.5%rdg±4dgt [20Hz – 1kHz] (0 – 40A) ±1.5%rdg±4dgt [50/60Hz] (20 – 200A) ±2.5%rdg±4dgt [20Hz – 1kHz] (20 – 200A) ±3.5%rdg [50/60Hz] (200 – 300A) ±4%rdg [20Hz – 1kHz] (200 – 300A) |
|---|---|
| DC A | 40/300A
±1%rdg±4dgt (0 – ±40A) ±1.5%rdg±4dgt (±20 – ±200A) ±3%rdg (±200 – ±300A) |
| Conductor size | Ø24mm max. |
| Frequency response | DC, 20Hz – 1kHz |
| Safety Standard | IEC 61010-1 CAT III 300V
IEC 61010-2-032 |
| Power source | LR-44 (1.5V) × 2 |
| Dimensions | 147(L) × 59(W) × 25(D)mm |
| Weight | 100g approx. |
| Included Accessories | 9090 (Carrying Case)
LR-44 × 2 Instruction Manual |
