Thông Số Kỹ Thuật
| AC A | 6/15/60/150/300A ±3% of FS |
|---|---|
| AC V | 150/300/600V ±3% of FS |
| DC V | 60V ±3% of FS |
| Ω | 1/10kΩ (25/250Ω mid-scale)
±2% of scale length |
| Temperature | Note: The MODEL2608A includes a temperature measurement scale,
but it is not available for new customers due to the discontinue of the Temperature Probe 7060. |
| Conductor size | Ø33mm max. |
| Frequency response | 50Hz/60Hz |
| Applicable standards | IEC 61010-1 CAT III 300V Pollution Degree 2
IEC 61010-2-031 IEC 61010-2-032 |
| Power source | R6 (AA) (1.5V) × 1 |
| Dimensions | 193(L) × 78(W) × 39(D)mm |
| Weight | 275g approx. |
| Included Accessories | 7066A (Test leads)
8923 (Fuse [0.5A/600V]) × 2 9097 (Carrying case) R6 (AA) × 1 Instruction Manual |
